Kane 958 Commercial Analyser (2025 Version) FREE GIFT CHOOSE BELOW

Original price was: £1,996.00.Current price is: £1,857.00.

Domestic, commercial & IAQ analyser with KANE LINK

Loading...

Description

All analysers come with a calibration certificate.

Please note: free gifts are non-returnable.

  • O2 & CO to 10,000ppm with H2 compensation
  • CO to 100,000ppm / 10% & 2 toxic gases option
  • MCERTS (pending) compatible option with KANE-GCU for NO2 & SO2
  • Purge pump prevents damage to CO sensor
  • Hydrophobic filter stops water damage
  • Hydrogen (H2) ready – up to 20% H2
  • Easy to use rotary dial & large display
  • Protective magnetic sleeve for hands free use & infrared link to optional KANE printer
  • KANE LINK wireless measurement & future proof promise
  • SEE, SAVE & SEND – KANE LINK transfers tests to KANE LIVE app

Additional information

Accessories

None, STANDARD KIT, PRO KIT, CPA KIT, PRO KIT 2, OIL KIT, COM-CAT KIT, CPA KIT 2, CMDDA KIT

Features

  • High capacity water trap & particle filter
  • Lifetime warranty under KANE CARE Service & Recertification – our promise to never let you down or your money back



Applications

  • Commercial, industrial & marine boilers up to 5MW / 50 bar stack draught
  • Combustion performance & efficiency
  • Structured let by, tightness & flue draught tests
  • Boiler & Heat pump temperature flow & return
  • IAQ – Room CO migration, temperature, RH & airflow



Measures

  • O2 0-21% ppm
  • CO 0-10,000ppm H2compensated with over range protection – 100,000ppm / 10% option
  • Option to measure 2 extra gases: NO to 5000ppm, NO2 to 1,000ppm & SO2 to 5,000ppm
  • Differential temperature -20 to +135°C
  • Differential pressure +/- 160mbar

Sensor options – up to 2

  • NO 0-5,000ppm
  • NO2 0-1,000ppm**
  • SO2 0-5,000ppm**
  • CO 0-10% replaces standard CO sensor*

Probe & accessory options

  • CHSP5 285mm high temperature PTFE lined smoke probe with removeable shaft & 4m neoprene hose
  • CHSLP5 1m high temperature PTFE lined smoke probe with removeable shaft & 4m neoprene hose
  • KMCE10 10m hose & thermocouple extension
  • KANE-GCU** Gas conditioning unit
  • KANE-IRP3 Printer

KANE LINK options

  • KANE-WPCP2 Wireless LINK temp clamp probes – connect as a pair
  • KANE-DTHA2 Wireless LINK airflow, temp & RH
  • KANE79 Wireless LINK CO monitor to 999ppm – connect up to 4



Fuel Types

  • 10 standard fuels including: – Natural Gas, LPG, Butane, Propane, Light Oil, Heavy Oil & user fuels



Calculates

  • CO2
  • CO/CO2 ratio
  • NOx (option)
  • Excess air
  • Combustion efficiency
